Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
1..6
Check the pump
(1)
Check to see if the all the connections of the pump are firm. Be sure
that the pump shaft rotates freely without problems.
(2)
Be sure that all cables are undamaged and comply with requirements.
Carry out the insulation leakage test. Dip the cable joints into the water for
12 hours. Use a 500V megaohm meter to test cable's insulation resistance.
The cold resistance should not less than 50 M.
(3)
Start the pump to see if the running direction complies with that
specified. Pay close attention that the idle running time is not more than 2
seconds.
(4)
After checking, attach the screen and cable guard plate to the inlet joint.
1..7
Unit Installation
(1)
First fix the prepared rope to the lifting ring on the outlet joint. If the
distance is less than 30m, the cord can be made of nylon, which has good
strength. The joints with the pump must be wear-resistant; otherwise, the
rope could be damaged due to vibration of the pump. When the distance
is over 30m, fix it with steel wire.
(2)
Connect pipes to the pump with the accessories, such as the thread
adaptor. Use wrench and pipe wrench to ensure the connection is tight.
(3)
Slowly place pump into the well and keep the pump upright. Bind
the cable to the pipe with the binding tape every two meters. Make
sure that cables are not pressed to the well wall during movement of
the pump, which will cause damage to the cable.
1..8
Warning for the installation
(1)
During the process of lowering the pump, if it becomes clogged,
do not force it down any further. This will avoid blockages and
possible damage to the pump.
(2)
Determine the depth of the pump below the surface according to the
mud and content condition of the well. Do not place the pump into the
mud. The distance between pump and the bottom of a well should not
more than 3 meters.
(3)
The distance from the submerged pump to the dynamic water level
should be less than 1 meter. Otherwise, it will cause damage to the
pump due to the idle running.
(4)
If the pump is installed too low a valve should be used on the
pipeline, outside the well, to control the flow rate and protect against
tripping of the control box or burnout of the motor caused by a too large
flow rate.
(5)
Connect the motor earth line correctly to avoid causing electric
shock due to electric leakage. Install
the pump as illustrated.
