No part name specs QTY manufacturer part code
1 fuse TLC-30A 30A/250V 1 SOC/TLNC-30A
LJP2E201KACBUD NICHICON
or 250CEBD200JA10 HITACHI
200µF/250VDC
420CEBD2500
2500µF/400VDC
4 terminal block 1 JX-W-4P-B 1 Leqing Huachen
5 terminal block 2 JXO-B3-1 1 Leqing Huachen
6 module board MITSUBISHI Module 30A 1 MITSUBISHI
7 radiator 1 Haiyang Guangming
8 rectifier 25A S25VB60 2
Japan New Power
Supply/American IR
9 PCB 1 0010451693
10 fan capacitor CBB61 4uF/450V 1 Ningbo Xinrong
No part name specs QTY position manufacturer
1 fuse 5*20 1A 1 FUS2 Lite, Ningli
2 fuse 5*20 3.15A 1 FUS1 Lite, Ningli
3 integrated circuit TLP521-1GB 2 O1,O2 Toshiba
4 integrated circuit TLP371 1 O3 Toshiba
5 integrated circuit 2003 1 U2
Toshiba，
ST,MOTOROLA
F3AA012E 12v RL1,RL2
JQ1a-12V RL3,RL4
7 relay G4A-1A-E 12VDC 1 RL5 OMRON
8 connector B2B-XH-A 2PIN red 1 CN101 JST JAM
9 connector B10B-XH-A 10PIN white 1 CN105 JST JAM
10 connector B11B-XH-A 11PIN white 1 CN106 JST JAM
11 connector B2P3-VH 2PIN white 1 CN107 JST JAM
12 connector B2P3-VH 2PIN red 1 CN108 JST JAM
13 connector B2P4-VH 2PIN white 1 CN109 JST JAM
14 connector B2P-VH 2PIN white 1 CN5 JST JAM
15 connector B2P-VH 2PIN red 1 CN6 JST JAM
16 connector B4B-EH-A 4PIN white 1 CN110 JST JAM
17 connector B4B-XH-A 4PIN white 1 CN111 JST JAM
18 connector SV40-05WSA 5PIN white 1 CN112 JST JAM
19 discharing tube RA-362M-V7 3600 V 1 SA1 MITSUBISHI
550NR-14D
Z301，Z302
Hokuriku
S14KV350
(with sleeve) Siemens
AU242AHBIA:
Main parts of electric control assembly
2
3
electrolytic
capacitor
1 HITACHI
6
20
electrolytic
capacitor
2
Main parts of PCB 0010451693
relay 4 Panasonic
2resistance
-260-
