>a__WcU[S^ <[c >a`V[e[a`Wc
No part name specs QTY position manufacturer
1 LED Φ3(red) 1 LED1
Tanwan Yiguang
Japan ROHM
2 fuse sleeve 1
3 fuse holder 2
4 current fuse T3.15/250VAC 1 FUSE Ningli/Lite
5 resistance S14K350/5/550NR-14D 1 VR Siemens/Hokuriku
6 relay
JQ1a/JQ1A(P)/G5SB-
1A/OJE-SS(H)-
112D(L)M/G5Q-1A/892(N)-
1AC-C 2 JK1 JK2
Panasonic,
Songchuan
7 relay JQ1/G5SB-1/892-1AC-C 1 JK3
Panasonic/Omron
/Songchuan
8 relay
JTN1S-TMP-F-DC12V
G4A-1A-E（priority of
use） 1 JK5
Panasonic,
Omron
9
voltage
stabilizer 7805 1 RG1 ST/ MOTOROLA
10 optical TLP371 1 IC1
11 optical TLP521 1 IC2
12 filter LX102 1 LX
13
current mutual
inductance 0057W 1 CT1
14 connector XHB2P3/B3B 1 CN1-white
15 connector VHB2B 2
CN2-red CN10-
white
16 connector XHB2B 3
CN3-white
CN11-blue
CN12-red
17 connector RTB-1.5-2P 1 CN4
18 lug 250 lug 8
S,N, N1, N2,N3,
FAN,ST,HB JST
TOSHIBA
JST
Leqing Huachen
AU142AFBEA,AU182AFBEA:
Main parts of electric control assembly
-261-
