![Haier AU142AFBEA [34/365] 1350 252 39](/img/pdf.png)
Haier AU142AFBEA [34/365] 1350 252 39
![Haier HCFU-12HA03/R1(B) [34/365] 1350 252 39](/views2/1821723/page34/bg22.png)
Unit model (color)
Type × Number
Speed(H-M-L) r/min
Fan motor output power kW
Air-flow(H-M-L) m³/h
Type / Diameter mm
Total Area m²
Temp. scope
℃
External
（L×W×H）
mm×mm×mm
Package
（L×W×H）
mm×mm×mm
Drainage pipe (material , I.D./O.D.) mm
Control type (Remote /wired)
Fresh air hole dimension mm
kW
dB(A)
kg / kg
Unit model (color)
Type × Number
Speed(H-M-L) r/min
Fan motor output power kW
Air-flow(H-M-L) m³/h
Type / Diameter mm
Total Area m²
Temp. scope
℃
External
（L×W×H）
mm×mm×mm
Package
（L×W×H）
mm×mm×mm
Drainage pipe (material , I.D./O.D.) mm
Control type (Remote /wired)
Fresh air hole dimension mm
kW
dB(A)
kg / kg
item Model
AC42NAFBEA
Indoor unit
White
Fan
1150/1000/900
Heat exchanger
Dimension
PVC 26/32
Remote
Centrifugal×4
0.14
2100/1800/1600
inner grooved pipe/φ7
0.808（1350*252*39.9）
2-7
1580*700*240
1710*790*315
Noise level (H-M-L)
Weight (Net / Shipping)
/
/
51.3/49.7/47.9
54/61
Electricity Heater
item Model
AC52NAFBEA
Indoor unit
White
Fan
Centrifugal×4
1250/1150/1000
0.14
2250/2100/1800
Heat exchanger
inner grooved pipe/φ7
0.808(1350*252*39.9)
2-7
Dimension
1580*700*240
1710*790*315
PVC 26/32
Remote
/
Electricity Heater /
Noise level (H-M-L)
53.2/51.0/49.8
Weight (Net / Shipping)
54/61
