Unit model (color)
Type × Number
Speed(H-M-L) r/min
Fan motor output power kW
Air-flow(H-M-L) m³/h
Type / Diameter mm
Total Area m²
Temp. scope
℃
External
（L×W×H）
mm×mm×mm
Package
（L×W×H）
mm×mm×mm
Drainage pipe (material , I.D./O.D.) mm
Control type (Remote /wired)
Fresh air hole dimension mm
kW
dB(A)
kg / kg
Unit model (color)
Type × Number
Speed(H-M-L) r/min
Fan motor output power kW
Air-flow(H-M-L) m³/h
Type / Diameter mm
Total Area m²
Temp. scope
℃
External
（L×W×H）
mm×mm×mm
Package
（L×W×H）
mm×mm×mm
Drainage pipe (material , I.D./O.D.) mm
Control type (Remote /wired)
Fresh air hole dimension mm
kW
dB(A)
kg / kg
item Model
AD242AMBEA
Indoor unit
Grey
Fan
centrifugal×2
/
0.1
1470/1300/1100
Heat exchanger
9.52
0.199
2-7
Dimension 990×650×300
1137×800×320
PVC 25/32
wired
/
Electricity Heater /
Noise level (H-M-L) 35/32/29
Weight (Net / Shipping) 40/57
item Model
AD242AHBEA
Indoor unit
Grey
Fan
centrifugal×2
/
0.13
900/1250/1500
Heat exchanger
TP2M/φ9.52
0.199
2-7
Dimension 820×830×360
940×1051×510
PVC 26/32
wired
/
Electricity Heater /
Noise level (H-M-L) 50/48/45/41
Weight (Net / Shipping)
24/27
