Haier AC092FEAHA [11/23] Name of each part
![Haier AB072FDBHA [11/23] Name of each part](/views2/1821873/page11/bgb.png)
Split type
Intake grill
Inlet
Air filter
Air guarding plate Air direction lower (internal)
(AS072,092,122,142FAAHA)
Inlet
Air filter (internal)
Outlet
Air guarding plate
(adjusting wind direction up and down)
Air direction lourer
(adjusting wind direction right and left)
(AS162,182,242FABHA)
Ceiling concealed type
electric box outlet
motor
fan motor
outlet frame
evaporater
motor
fan motor
outlet frame
evaporater
AE242FLAHA
AE072FEAHA
AE122FEAHA
AE162FEAHA
AE092FEAHA
AE142FEAHA
AE182FEAHA
AE242FEAHA
(AS072,092,122,142FABHA)
(AS162,182,242FAAHA)
AE242FLBHA
AE092FEBHA
AE142FEBHA
AE182FEBHA
AE072FEBHA
AE122FEBHA
AE162FEBHA
AE242FEBHA
Name of Each Part
9
