Haier AC092FEAHA [3/23] Specifications
![Haier AC282FEAHA [3/23] Specifications](/views2/1821873/page3/bg3.png)
Do not damage any parts of the
air conditioner that carry refrigerant by
piercing or perforating the air
conditioner's tubes with sharp or pointed
items,crushing or twisting off the
surfaces. If the refrigerant spurts out
and gets into eyes , it may result
in serious eye injures.
Always remember to unplug the air
conditioner before openning inlet grill .
Never unplug your air conditioner by
pulling on the power cord. Always grip
plug firmly and pull straight out from
the outlet.
All electrical repairs must be carried
out by qualified electricians. Inadequate
repairs may result in a major source of
danger for the user of the air conditioner.
Cautions
For the purpose of the safety, the air
conditioner must be properly grounded
in accordance with specifications.
Do not allow children to play with
the air conditioner. In no case should
children be allowed to sit on the outdoor
unit.
Do not obstruct or cover the ventilation
grille of the air conditioner. Do not put
fingers or any other things into
the inlet/outlet and swing louver.
Specifications
1) The refrigerating circuit is leak-proof.
2)Please keep the air-conditioner under
conditions in the following table during
operation to ensure proper use of it.
Outdoor temperature
(D.B.)
Indoor temperature
(W.B.)
Indoor humidity
Outdoor temperature
(W.B.)
Indoor temperature
(D.B.)
Above-5 C and below 43 C
Above15.5 C and below24 C
Humidity under 80%
Whenever air-conditioner is op-
erating under circumstance with
humidity above 80% for long
term, defrosting shall be formed
and dropped on the machine
surface, mirage shall be blew off
from the outlet.
Above-15 C and below 15.5 C
Above-15 C and Below 28 C
Cooling Heating
3)The wiring diagram refer to the wiring
diagram on the indoor and ortdoor units.
4) If the fuse on electrical heater is
broken please change it with the type
of AC 250V 15A
If the fuse on main circuit is broken
please change it with the same type
ofAC 250V 5A
5)For AS072 ~ 182FA AHA the indoor
unit installation height is at least 2.0m.
1
