Commercial Air Conditioner Model: heat pump, 10SEER UNITS
42
Run or start capacitor defective Replace
Loose connection Check and tighten all connections.
Compressor stuck, grounded or open
motor winding, open internal overload
Wait for 2 hours for overload to reset.
Replace compressor if still open.
Low voltage condition At compressor terminals, voltage must be
within 10% of rating plate volts when unit is
running.
Condenser fan runs,
compressor doesn’t
Low voltage condition Add start kit components
Run capacitor defective Replace
Loose connection Check and tighten all connections.
Fan stuck, grounded or open motor
winding, open internal overload
Wait for 2 hours for overload to reset.
Replace Fan if still open.
Low voltage condition At compressor terminals, voltage must be
within 10% of rating plate volts when unit is
running.
Defective overload protector Replace – check for correct voltage
compressor runs,
Condenser fan
doesn’t
Refrigerant undercharge Add refrigerant
Register sweat Low evaporator airflow Increase blower speed or reduce restriction
– replace air filter
Restriction in liquid line, metering
device or filter drier
Replace defective components
Flowrator piston size too small Change to correct size piston
High head – Low
vapor pressures
Incorrect capillary tubes Change coil assembly
Blocked outdoor coil Clear away leaves and other debris
Refrigerant overcharge Correct system charge
Condenser fan not running Repair or replace
High head – High or
normal vapor
pressures
Air, non-condensibles or moisture in
system
Recover refrigerant, evacuate & recharge,
add filter drier
Flowcheck piston size too large Change to correct size piston
Defective compressor valves Replace compressor
Low head – High
vapor pressures
Incorrect capillary tubes Replace coil assembly
Low evaporator airflow Increase blower speed or reduce restriction
– replace air filter
Operating below 65 °F outdoors
Add low ambient kit
Low vapor – cool
compressor – iced
evaporator coil
Moisture in the system Recover refrigerant, evacuate & recharge,
add filter drier
Excessive load Recheck load calculation High vapor pressure
Defective compressor Replace
Fluctuating head and
vapor pressures
Air or non-condensibles in system Recover refrigerant, evacuate & recharge.
Pulsing noise at
metering device or
liquid line
Air or non-condensibles in system Recover refrigerant, evacuate & recharge
