Intense
Speed up
Speed
T e mp
DelayExtra RinseHighwash Rinse Hold
Start/
Pause
Power
Prewash
Cotton
Synt-
hetic
Wool
Comfort 40
Mixed
Drain
Spin
Rinse
Hand
wash
Sport
Jeans
2
1
3
DelayExtra rinseDry ECOStart/Pause
Wash RinseSpinDry
Temp
Speed
Prewash
Cotton&Linen
Synthetics
Wool
Quickwash
Wash
Rinse
Spin
Dry
Iron
Air wash
14
USING THE APPLIANCE
USING THE APPLIANCE
LOADING THE MACHINE
Open the washer door, put in the laundry piece by piece. Close the door tightly.
¬ When first using the Washer Dryer, let it run empty without detergent for one
quick wash cycle to prevent the laundry from being tainted by oil or dirty water
from the Washer Dryer.
¬ Do not overload the Washer Dryer.
SELECTING PROGRAM
To get the best washing results, an appropriate washing program should be selected according
to the laundry type. Please turn the program knob clockwise to select the right program.
SELECTING FUNCTIONAL
Select the required options. (Refer to the "Control panel" pages 09 and 10).
Otherwise keep all the buttons deselected. If you wish to dry your laundry directly
after the wash cycle is finished, please press the "Dry"-button.
SELECTING DETERGENT
The washing efficiency and the performance is determined by the quality of detergent
used. Special non-foaming detergent produces good washing results. Use specific
detergents for synthetic and woollen goods. Do not use dry cleaning agents such as
trichloroethylene and similar products.
Note: Do not add more detergent than needed. Please follow the dosage
recommendation on the detergent package.
ADDING DETERGENT
Slide out the detergent drawer and put the required detergent and softening agent
into the corresponding compartments. Push back the drawer gently. (Refer to the
instructions on the drawer)
Caution:
¬ For pre-washing program, detergent should be added to both compartments 1 and
2. For other programs, do not add detergent to compartment 1.
¬ If liquid detergent will be used, please fill in to the dosage cup and place it directly
into the drum together with the laundry.
¬ Do not overuse softener; otherwise, it will damage the artificial fibers.
WASHIng&DRYIng
