![Haier HWD-C1000TXVE ME-U [18/21] Maintenance](/views2/1827308/page18/bg12.png)
Quickwash
Wool
Synthetics
Cotton&Line
Prewash
Spin
Dry
Iron
Air wash
T e mp
Speed
W
Quickwash
Wool
Synthetics
Cotton&Linen
Prewash
Rinse
Spin
Dry
Iron
Air wash
T e mp
Speed
DelayExtra
rinse
DryEcoTime Start/
Pause
Wash
Start/Stop
Powe r
2.
4.
5.
1.
3.
DelayExtra rinseDry ECOStart/Pause
Wash RinseSpinDry
Temp
Speed
Prewash
Cotton&Linen
Synthetics
Wool
Quickwash
Wa sh
Rinse
Spin
Dry
Iron
Air wash
18
MAiNtENANcE
WAtER iNLEt AND iNLEt FiLtER
To prevent blockage to the water supply by ingress of foreign
substances, clean the water inlet and inlet filter regularly.
MOviNg thE MAchiNE
If the machine is to be moved to a distant location, replace
the transportation locks removed before installation to prevent
damage as shown below.
1. Remove the blanking plugs.
2. Remove the back cover
3. Insert the synthetic stabilisers and the transportation bolts.
4. Tighten the bolts with a spanner.
5. Replace the back cover.
LONg pERiODS OF DiSUSE
If the washer dryer is left idle for a long period, pull out the
electrical plug and turn off the water supply. Open the washer
dryer door to prevent formation of moisture and odours. Let
the door open while not used.
CLEAnIng&CARE
