![Haier HWD-C1000TXVE-U [15/21] Using the appliance using the appliance using the appliance](/views2/1827308/page15/bgf.png)
DelayExtra rinseDry ECOStart/Pause
Wash RinseSpinDry
Temp
Speed
Prewash
Cotton&Linen
Synthetics
Wool
Quickwash
Wash
Rinse
Spin
Dry
Iron
Air wash
DelayExtra rinseDry ECOStart/Pause
Wash RinseSpinDry
Temp
Speed
Prewash
Cotton&Linen
Synthetics
Wool
Quickwash
Wash
Rinse
Spin
Dry
Iron
Air wash
DelayExtra rinseDry ECOStart/Pause
Wash RinseSpinDry
Temp
Speed
Prewash
Cotton&Linen
Synthetics
Wool
Quickwash
Wa sh
Rinse
Spin
Dry
Iron
Air wash
DelayExtra rinseDry ECOStart/Pause
Wash RinseSpinDry
Temp
Speed
Prewash
Cotton&Linen
Synthetics
Wool
Quickwash
Wash
Rinse
Spin
Dry
Iron
Air wash
15
USiNg thE AppLiANcE
USiNg thE AppLiANcE
USiNg thE AppLiANcE
WASHIng & DRYIng
WAShiNg
Press the Start/Pause button. The Washer Dryer will operate according to the
pre-set programs. The Washer Dryer will stop operation automatically when a
washing cycle ends. The "End" sign will appear on the display. Open the washer
door and take out the laundry.
DRYiNg
If you wish to dry wet laundry, please select one of the drying programs by
turning the program knob (Refer to the "Control panel" pages 09 and 10).
AFtER USiNg thE AppLiANcE
Turn off the water supply and unplug the power cord. Open the washer door to
prevent formation of moisture and odours. Let the door open while not used.
SEttiNg SpiN SpEED
Press and hold down the speed button until the desired speed is selected or the
symbol "--" is selected for no spin. See "Operational functions" on the "Control
panel" pages (09 and 10) for selecting temperature and spin speed. It is
advisable to select the recommended value.
SEttiNg WAShiNg tEMpERAtURE
Press and hold down the temperature button until the desired temperature is
selected or the symbol
-
for no water heating.
tipS FOR SAviNg ENERgY
1. Collect clothes for one full wash load.
2. Avoid overloading the washer dryer.
3. Pre-wash only heavily soiled clothes.
4. Reduce the amount of detergent or choose the speed up wash programs for slightly soiled clothes.
5. Choose a proper washing temperature. Modern detergents can wash with very good result already in lower temperature
than 60°C. Only user higher temperature than 60° for heavily soiled laundry.
6. Follow the dosage recommendation on the detergent package to avoid using too much detergent.
7. Softening agent makes clothes feel softer and easier to iron.
8. Adding fabric conditioner will also get rid of static condensation to make ironing easier.
