Haier HWD-C1200TXVE-U [5/21] Before use
![Haier HWD-C1200TXVE-U [5/21] Before use](/views2/1827308/page5/bg5.png)
Quickwash
Wash
Wool
Synthetics
Cotton&Linen
Prewash
Rinse
Spin
Dry
Iron
Air wash
Temp
Speed
Delay Extra
rinse
Wash+Dry
Eco
Start/
Pause
Quickwash
Wool
Synthetics
Cotton&Linen
Prewash
Rinse
Spin
Dry
Iron
Air wash
Temp
Speed
Wash
Spin Dry
Wash
Rinse
SENSOR DRY
05
BEFORE USE
pREpARiNg thE MAchiNE
Remove all the packing materials to prevent unsteadiness, including the
polystyrene base.
Upon opening the package, water drops may be seen on the plastic bag and the
porthole. This is normal phenomenon resulting from water tests in the factory.
DEScRiptiON
Drain hose
Water inlet valve
Power cord
Back cover
Back cover screws (3)
Transportation bolts (3)
Power switch
Program knob
Door handle
Display
Porthole
Washer door
Detergent distribution drawer
Filter cover
pR EpAR AtIon
This diagram may be slightly different from the layout of the washer
dryer you have just purchased due to technical improvements.
