Page 10

The height of the drainage outlet must be 80-100cm. To prevent the drainage hose from dropping off,

fix it to the drainage hose clip at the back of the washing machine.

Before connecting to the power supply, check:

Joining the Inlet Hose to the Washing Machine

Connect of water inlet valve

Connect the nut on the inlet hose to the connector on the water valve.

Installation

Use the drainage holder to keep the end of the drainage hose retained and to prevent the outflow

of water . It is recommended that drainage hose extensions not be used; if an extension is needed,

please consult a serviceman. The additional hose should be no more than 250cm (overextended

hoses could lead to siphonage). Note: The drainage hose should not be submerged in water and

should be securely fixed and leak-free.The appliance is to be connected to the waster mains using

new hose-sets and that old hose-sets should not be reused.

Connecting to the Power Supply

The socket is adequate for the maximum power of the washing machine (For safety, fuses in the power circuit should be rated

for no less than 15A).

The power outlet should be capable of accepting the washing machine plug. The washing machine must be earthed before

use.

Supplementary earth cable should not be necessary if the socket is connected to the earth

Supplementary earth cable shoulde be installed on the upper back of the washing machine andconnected to an earth if the

power supply socket has no earth connection

The voltage should meet the requirement.

Front Load Washing Machine

Model:HNS1460TVE/ME

80cm

100cm
