![Haier HNS1460TVEME [5/27] Front load washing machine](/img/pdf.png)
Haier HNS1460TVEME [5/27] Front load washing machine
![Haier HNS1460TVE [5/27] Front load washing machine](/views2/1828206/page5/bg5.png)
Page
SPECIFICATION
Proposal 2007
New Sensor
Front load washing machines
Brand position center upper frame of door / chromed sticker
Model number serigraphy right top corner control panel
On white: silver / On silver : black or dark grey
1. Product identification
Description of appliance Washing machine
Type of appliance (FS = standing, BI = built-in)
FS
Supplier own brand Haier
Supplier bar code EAN
Mares computer code
Commercial Brand / Model
Commercial bar code EAN
2. Key-Features
Energy efficiency class A
Washing performance class A
Spin efficiency class B
Programs
n°
11
Capacity
Kg
Max. 6
Spin speed (max. / optional)
rpm 1400-0
Noise level dB(A) 71
Energy consumption per wash circle * kWh 0.95
Water consumption* l
<49
Residual dampness (spin result) % 56%
Spin speed selector switch (steps) rpm
1400/1200/1000/800/600/400/0
Spin speed variator (stepless) rpm
Adjustable thermostat (water temp. adjust from -
to)
°C 90 -
Drum capacity dry laundry / water kg / l 6/49
Auto water level adjust (depending on volume of filled in laundry)
AWL
Washing time (max.) min 178(TBC)
Washing temperatures (program-controlled) °C 30/40 / 60 / 90
Certification's (CE / ISO 9001 / ISO 9002) CE / ISO 9001
Approvals (VDE/GS / TÜV/GS / IMQ) TÜV/GS (Rhl.)
*EN60456(60°C cycle, full load without pre-wash)
=
COLD
3. Basics data
Unit dimensions (H x W x D) cm 85 x 59.5x 56.5
Net weight kg 70
Voltage/frequency V/Hz 220-240V~50Hz
Input power / main fuse (intensity) W/A 2000/10
Work top / removable /
Control M = electromechanical, E = electronic,
F = fuzzy
E
Drum S = stainless steel / Z = zinc coated S
Tub P = Polyprop./ S = stainless steel P
Door:
aesthetic (R = round, Y = big eye, Q =
square)
R
Diameter cm 30
Outer door frame S= stainless steel / M
=metal/P = plastic
P
Inner door G= glass / P=
plastic
G
Detergent compartments n° 3
Removable compartment for liquid detergent -
Front Load Washing Machine
Model:HNS1460TVE/ME
