Page 19
Error message. Motor overheat protection or damaged.
Troubleshooting:
Y
Cut off power and check if motor wires
are connected well
Reconnect well
N
N
Put the motor in normal temperature about
ten minutes, and then test again. If the
resistance is natural, it is caused by
overheated protection. Then check and
deal with overload, abnormal voltage. If
not, please replace motor
Y
Measure if resistance of motor winding by
multimeter, is it as followed?
Y
Repair wires
Pull out the wire connection of motor
Then check if circuit
is open by multimeter
1
3
7
2
5
8
1-2(between white a nd white):5
3-5(between brown and red):3.4
7-8(between grey and black): 4 0
Front Load Washing Machine
Model:HNS1460TVE/ME
