OPERATING INSTRUCTIONS
Including soak Not including soak
Normal About54-78 About44-58
Heavy Duty About57-91 About47-61
Whites About53-89 About43-59
colors About50-86 About40-56
Hand Wash / About26-38
Quick Wash / About24-30
Delicate Casual / About25-35
Wrinkle control / About25-34
Program
Total time
