OPERATING INSTRUCTIONS
Bleachdispenser is located on front corner under the loading door.
Pour in recommended amount of bleach into dispenser during the
first wash fill.
Note:Use only liquid bleach in dispenser.
Warning:
Softener inlet
Please follow softener instructions for dose usage.
Before washing put the softener into the filling entrance(can be found on the
balancing ring by rotating the inner tub, as
illustrated in the drawing).
Please do not use softener in the following cases Selected rinsing times more
than two; Choosing rinse/spin two-in-one program.
Softener inlet
SOFTENER
Try to avoid adding softener in, if you do not intend to wash immediately. The
softener may harden and may cause a poor flow.
Use the manufacturer s chart,on product container for
recommended use of liquid or powder bleach.
Be careful not to spill undiluted bleach on the washer cabinet or
your clothes. As it is a storng chemical, it may damage some of
your clothes or the finish of the washer if not properly diluted.
Bleach Dispenser:
