Haier GWT900AW [21/26] How to disassemble washing machine
![Haier HLT364XXQ [21/26] How to disassemble washing machine](/views2/1828218/page21/bg15.png)
HOW TO DISASSEMBLE WASHING MACHINE
No Component Step Picture
6 top lid dismantle the screw of the top lid
7
dismantle the screw of the lid
switch
8 take off the lid switch
dismantle the connector of the
part
dismantle the wire connector
dismantle the
lid switch
dismantle the
wire module
9
20
