Installation Manual

CAUTION

Precautions before reading the installation manual.

1. PRECAUTIONS

Read this user manual carefully before installing the equipment.

The air conditioner must be installed by professional technicians.

When installing the indoor unit and its accessory pipes, adhere to

this user’s manual as far as possible.

Inspect and make sure the piping and cabling are correct before

powering on the air conditioner.

This information may change with the update of this machine, and

no further notice will be given for such change.

WARNING

The safety precautions listed here are divided into two categories. In

either case, important safety information is listed which must be read

carefully.

After completing the installation, make sure that the unit operates

properly during the start-up operation. Please instruct the customer

on how to operate the unit and keep it maintained.Also, inform

customers that they should store this installation manual along with

the owner's manual for future reference.

Do not throw or slam the remote controller.

Operate the remote controller within the receiving scope of the

indoor unit, and direct the transmitting part of the remote control-

ler to the receiver of the indoor unit.

The remote controller should be over 1m away from the

television or sound box.

Do not place the remote controller at a moist place, near the

heat sources such as stove, or expose it directly in the sunlight.

Ensure correct positive and negative poles when loading the

batteries.

Decide the correct way of conveying the equipment.

Try to transport this equipment with the original package.

If the a ir conditioner needs to be installed on a metal part of the

building, electric insulation must be performed, and the installa-

tion must meet the relevant technical standards of electric

devices.

The appliance must be installed 2.3m above floor.

The appliance shall not be installed in the laundry.

Before obtaining access to terminals, all supply circuits

must be disconnected.

The appliance must be positioned so that the plug is

accessible.

The enclosure of the appliance shall be marked by word, or

by symbols, with the direction of the fluid flow.

If the supply cord is damaged, it must be replaced by the

manufacture or its service agent or a similarly qualified

person in order to avoid a hazard.

An all-pole disconnection switch having a contact

separation of at least 3mm in all poles should be

connected in fixed wiring.

Failure to observe a warning may result in death.

CAUTION

Failure to observe a caution may result in injury or damage

to the equipment.

Install the unit where enough space of installation and mainte-

nance is available.

Install the unit where the ceiling is horizontal and enough for

bearing the weight of the indoor unit.

Install the unit where the air inlet and outlet are not baffled and

are the least affected by external air.

Install the unit where the supply air flow can be sent to all parts

in the room.

Install the unit where it is easy to lead out the connective pipe

and the drain pipe.

Install the unit where no heat is emitted from a heat source

directly.

CONTENTS PAGE

PRECAUTIONS.......................................................................................1

ACCESSORIES (INDOOR UNIT).............................................................. 2

INSTALLATING INDOOR UNIT ................................................................2

INSTALLATING OUTDOOR UNIT...............................................................4

HEAT INSULATION OF THE PIPE .............................................................8

INSTALL THE CONNECTIVE PIPE.............................................................8

INSTALL THE DRAIN PIPE......................................................................11

ELECTRIC CONNECTION........................................................................11

ELECTRIC WIRE DIAGRAM....................................................................13

METHODS OF CONFIGURING AND SELECTING INSTALLATION...............15

CONSTRUCTION AND VENTILATION PIPELINE DESIGN SCHEME............16

TRIAL RUN............................................................................................17
