11 INSTRUCTION MANUAL

 Take hold of the mixer (4) and then, by pressing and holding the release button (11), remove the

mixer from the bracket (9) in an upward direction.

 Insert the whisk attachment (5) or the dough mixing attachment (6) into the corresponding slots in

the mixer (4) until it clicks. Both nozzles must be securely fixed in the holes of the mixer (13)

 Place the necessary ingredients in a suitable container or bowl (7).

 Plug the power cord into an electrical outlet.

 Turn on the mixer with the mode switch (2) and select the desired speed of rotation of the nozzles

«1, 2, 3, 4, 5».

 When you press and hold the "TURBO" button (3), the device will run at maximum speed.

 After the operation is complete, set the operating mode switch (2) to the "0" position and remove

the plug from the power outlet.

 Press the button (1) to remove the installed attachments (5 or 6).

Attention! Do not press the attachment release button (1) while the device is running.

Using a holding stand (12)

For more complex cooking tasks, you can install the mixer (4) on a holding stand (12):

 Press the «RELEASE» button (10) and lift the bracket (9) until it is locked in the upper position.

 Place the mixer bowl (7) on the holding stand (12)

 Insert the whisk attachment (5) or dough mixing attachment (6) into the corresponding slots (13) of

the mixer (4) until it clicks. Both nozzles must be securely fixed in the holes of the mixer (Fig. 1, 2).

Note: for correct Assembly, the nozzle with a plastic gear (5 or 6) should be installed in the hole in

the mixer housing (4), which has a star marking around the perimeter.

 Place the mixer (4) on bracket (9) by aligning the clips on the bracket (9) with holes in casing (4), and

click on the mixer to trigger locks (Fig. 8). With this plastic gear of the nozzle must match the hole in

the bracket (9) in which is installed a plastic bushing.

 Lift the bracket (9) with the mixer (4) mounted on it up by pressing the «RELEASE» button (10).

 Place the necessary ingredients in a bowl (7).

 Press the «RELEASE» button (10) and lower the bracket (9) with the mixer (4) down until it is fixed.

 Plug the power cord into an electrical outlet.

 Turn on the mixer with the mode switch (2) and select the desired speed of rotation of the nozzles

«1, 2, 3, 4, 5».

 When you press and hold the «TURBO» button (3), the device will run at maximum speed.

 Attention! Be careful! During the operation of the mixer (4) on the holding stand (12), the bowl (7)

rotates, and the mixer (4) with the bracket (9) performs oscillatory movements in the horizontal

plane. Do not touch the rotating parts of the device. Do not allow hair or loose clothing items to

enter the rotation zone.

 Do not allow foreign objects to enter the bowl.

 After the operation is complete, set the operating mode switch (2) to the «0» position and remove

the plug from the power outlet.

 Lift the bracket (9) with the mixer (4) mounted on it up by pressing the release button (10).

 Take hold of the mixer (4) and then, by pressing and holding the release button (11), remove the

mixer from the bracket (9) in an upward direction.
