11 INSTRUCTION MANUAL

Dry Ironing

 Connect the appliance to the mains, set the desired ironing temperature according to the fabric

type.

 Set the steam regulator to the minimum «0» position.

 When the heat indicator turns off, it means that the iron has warmed up, has reached the

selected temperature and is ready for dry Ironing.

 You can iron in dry mode even if the tank is filled with water. However, in case of continuous

operation in this mode it is not recommended to pour too much water into the tank.

 Attention! If during operation you need to use steam and there is no water in the tank,

disconnect the iron from the mains and wait until it cools down, and only then fill in the water.

 If you need to wet the cloth, press the water spray button (10). Water sprayed through the

spraying device, evenly moistens the product.

 At the end of Ironing, allow the sole of the iron to cool to room temperature and disconnect

the device from the mains.

 Attention! If you need to switch from high temperature to lower temperature, set the desired

temperature using the temperature controller (4).

 To avoid damage to things you need to wait for the cooling of the sole of the iron. With the

constant glow of the indicator of the heating it is possible to continue Ironing.

Spray function (10)

 In any Ironing mode, press the water spray button to moisten the cloth (10).

 Sometimes it is necessary to press the button several times, while in the tank should be water.

Burst of steam

 This function provides an extra amount of steam to remove stubborn wrinkles.

 Set the steam regulator (8) to «0», then fill the water tank with distilled or boiled water (not

more than 350 ml).

 Plug the iron into an outlet, set the temperature regulator and the steam regulator (4) to the

maximum position.

 Luminous heat indicator informs about the heating of the iron. When the indicator (8) goes out,

it means that the set temperature is reached.

 To obtain a powerful steam boost, press the steam boost button (twice to three times for a

short period of time. When steaming, a small amount of hot water can be discharged from the

outlet of the sole of the iron. If you press the steam button (9) too often, the temperature of

the sole of the iron may fall below the set temperature. Stop pressing the steam button and let

the iron heat up (1).

 At the end of Ironing, allow the sole of the iron to cool to room temperature and disconnect

the device from the mains.

 Do not press this button more than 3 times at once.

Auto shut off

The light comes on to indicate that shut off has tripped. As soon as you move the iron, the device

turns off and the iron starts working again.
