1.4. Operation range
1.4.1. Power Supply
The applicable voltage range for each unit is given in the following table. The working voltage among the three phases must be
balanced within a 3% deviation from each voltage at the compressor terminals. The starting voltage must be higher than 85% of
the rated voltage.
MODEL Unit Main Power Applicable Voltage
CU- Phase, Volts Hz Max Min
L34DBE5 1~240 50 264 216
L43DBE5 1~220 50 242 198
1~230 50 253 207
L50DBE8 3N~380 50 418 342
3N~400 50 440 360
3N~415 50 457 374
1.4.2. Indoor and Outdoor Temperature
•
• •
•
Model 50Hz CU-L34DBE5, CU-L43DBE5, CU-L50DBE8
Operating Hz Indoor Temp. (D.B./W.B.) (°C) Outdoor Temp. (D.B./W.B.) (°C)
Max Min Max Min
Cooling 50 32/23 21/15 43/- -15/-
Heating 50 27/- 16/- 24/18 -20/-
4
