Panasonic CS-F50DB4E5 [6/110] Hot start system heat pump models

2.1.8. Piping and drainage

•

• •

•

Built-in upward draining mechanism.

2.1.9. Automatic changeover function (heat pump models)

•

• •

•

The unit automatically switches between cooling and heating in accordance with operating load in order to maintain a

comfortable indoor temperature.

2.1.10. Hot start system (heat pump models)

CS-F50DB4E5 CU-L50DBE8
