10
Item Unit
Tank Heater [1 Phase, 230V]: Max. Current / Max.
Input Power
A / kW 13.0 / 3.00
Power Factor
% 96
Power factor means total figure of compressor and outdoor fan motor.
Number of core -
Power Cord
Length m (ft) -
Thermostat
Electronic Control
Protection Device
Electronic Control
Item Unit Indoor Unit
Performance Test Condition
EUROVENT
Outdoor Ambient °C -20 ~ 35
Operation Range
Water Outlet °C 25 ~ 55
Internal Pressure Differential
kPa 23.0
dB (A) 30
Noise Level
Power Level dB 43
Height mm (inch) 892 (35-1/8)
Width mm (inch) 502 (19-3/4)
Dimension
Depth mm (inch) 353 (13-29/32)
Net Weight
kg (lbs) 51 (113)
Liquid mm (inch) 9.52 (3/8)
Refrigerant Pipe Diameter
Gas mm (inch) 15.88 (5/8)
Inlet mm (inch) 28 (1-3/32)
Water Pipe Diameter
Outlet mm (inch) 28 (1-3/32)
Water Drain Hose Inner Diameter
mm (inch) 15.00 (19/32)
Motor Type Capacitor Run Induction Motor (5 μF)
No. of Speed 3
Pump
Input Power W 180
Type Brazed Plate
No. of Plates 80
Size (H x W x L) mm 130 × 93 × 325
Hot Water Coil
Water Flow Rate l/min (m
3
/h) 40.1 (2.4)
Pressure Relief Valve Water Circuit
kPa Open: 190, Close: 183 and below
Flow Switch
Magnetic Lead Switch
Protection Device
A Residual Current Circuit Breaker (1 Phase: 40 & 3 Phase: 25)
Volume I 10
Expansion Vessel
MWP bar 1
Capacity of Integrated Electric Heater
kW 9.00
Note:
Heating capacities are based on outdoor air temperature of 7°C Dry Bulb (44.6°F Dry Bulb), 6°C Wet Bulb
(42.8°F Wet Bulb) with controlled indoor water inlet temperature of 30°C and water outlet temperature of 35°C.
Specification are subjected to change without prior notice for further improvement.
