11
2.4 WH-SDF16C9E8 WH-UD16CE8
Item Unit Outdoor Unit
Performance Test Condition
EUROVENT
kW 16.00
BTU/h 54600
Heating Capacity
kcal/h 13760
W/W 4.23
COP
kcal/hW 3.64
dB (A) 53
Noise Level
Power Level dB 70
Air Flow
m
3
/min (ft
3
/min) 90.0 (3180)
Refrigeration Control Device
Expansion Valve
Refrigeration Oil
cm
3
FV50S (1200)
Refrigerant (R410A)
kg (oz) 2.75 (97.1)
Height
mm (inch) 1340 (52-3/4)
Width
mm (inch) 900 (35-7/16)
Dimension
Depth
mm (inch) 320 (12-19/32)
Net Weight
kg (lbs) 109 (240)
Liquid
mm (inch) 9.52 (3/8)
Pipe Diameter
Gas
mm (inch) 15.88 (5/8)
Standard Length
m (ft) 7 (23.0)
Pipe Length Range
m (ft) 3 (9.8) ~ 40 (131.2)
I/D & O/D Height Difference
m (ft) 30 (98.4)
Additional Gas Amount
g/m (oz/ft) 50 (0.5)
Refrigeration Charge Less
m (ft) 30 (98.4)
Type
Hermetic Motor
Motor Type
Brushless (4-poles)
Compressor
Rated Output
kW 4.30
Type
Propeller Fan
Material
PP
Motor Type
Induction (8-poles)
Input Power
W —
Output Power
W 60
Fan
Fan Speed
rpm 580 (Top Fan) 620 (Bottom Fan)
Fin material
Aluminium (Pre Coat)
Fin Type
Corrugated Fin
Row × Stage × FPI
2 × 51 × 18
Heat Exchanger
Size (W × H × L)
mm 881.5 × 1295.4 × 44
Item Unit
ø Three
V 400
Power Source (Phase, Voltage, Cycle)
Hz 50
Input Power
kW 3.78
Starting Current
A 5.7
Running Current
A 5.7
Max. Current / Max. Input Power Heatpump Unit
(Heatpump Unit + Back-up Heater)
A / kW 9.9 / 6.59 (Separate ELCB)
Back-up Heater: Max. Current / Max. Input Power
A / kW 13.0 / 9.00
