Troubleshooting guide

Carefully read the instruction to make sure the unit is being operated properly. Check the

following before you take your unit to the local dealer for repair.

Symptom Possible cause Solution

No sound The volume control regulator set in the

minimal position

Adjust sound level

Bad power connections Check to see that all the power and

speaker leads are securely connected

The audio cassette receiver is

damaged

Take your unit to the local dealer for

repair

Unnatural

sound

Acoustic system cables are connected

without observance of polarity (+ or -)

Check to see that all the power and

speaker leads are securely connected

Damaged speaker wire or speaker Replace the speaker or speaker wires

The audio cassette receiver is

damaged

Take your unit to the local dealer for

repair

Good ground connections eliminate most electrical noise problems and require tight

contact with the metal vehicle chassis.

Specification

Loudspeaker сone woofer: 16 х 24 cm IMPP cone

midrange: 55 mm mylar

tweeters: 20 mm piezo

Magnet 20 Oz

Peak output power 240 W

Rated output power 120 W

Impedance 4 Оhm

Sensitivity 92 dB

Frequency response 45 – 20000 Hz

Dimensions 262 x 185 х 105 mm

Net/Gross weight 1.6 kg/3.25 kg

Gift box dimension (L x Н х W) 360 mm х 137 mm х 297 mm
