Connecting the Display

Disassembling the stand

1. Put a cushion or soft cloth on aflat

surface.

3. 4. Remove the Stand Body and Stand

Base from product in correct

direction as shown in the picture.

2. Place the monitor face Down on the

cushion or soft cloth.

Use a coin on the back of the Stand

Base and turn the screw anticlock-

wise to loosen.
