- 8
Subject to technical modifications!
We hereby declare that the machine de-
scribed below complies with the relevant ba-
sic safety and health requirements of the EU
Directives, both in its basic design and con-
struction as well as in the version put into cir-
culation by us. This declaration shall cease to
be valid if the machine is modified without our
prior approval.
The undersigned act on behalf and under the
power of attorney of the company manage-
ment.
Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Phone: +49 7195 14-0
Fax: +49 7195 14-2212
Technical specifications
Water connection
Max. feed temperature °C 40
Min. feed volume I/min 10
Max. feed pressure MPa 0,8
Max. Suction height m 0,5
Electrical connection
Voltage
1~50 Hz
V230
Connected load kW 2,1
Mains fuse (slow-blow) A 10
Protective class I
Protection class IP X5
Performance data
Working pressure MPa 12,5
Max. permissible pressure MPa 14
Water flow rate I/min 7,5
Dimensions and weights
Length mm 876
Width mm 325
Height mm 285
Weight, ready to operate with
accessories
kg 13
Detergent flow rate I/min 0,3
Recoil force of trigger gun N 15
Values determined as per EN 60335-2-79
Hand-arm vibration value
Uncertainty K
m/s
2
m/s
2
< 2,5
0,3
Sound pressure level L
pA
Uncertainty K
pA
dB(A)
dB(A)
71
2
Sound power level L
WA
+ Un-
certainty K
WA
dB(A) 86
CE Declaration
Product: High-pressure cleaner
Type: 1.181-xxx
Relevant EU Directives
2006/42/EC (+2009/127/EC)
2004/108/EC
2000/14/EC
Applied harmonized standards
EN 55014–1: 2006
EN 55014–2: 1997 + A1: 2001
EN 60335–1
EN 60335–2–79
EN 61000–3–2: 2006
EN 61000–3–3: 2008
EN 62233: 2008
Applied conformity evaluation method
Appendix V
Sound power level dB(A)
Measured: 84
Guaranteed: 86
CEO
Head of Approbation
18 EN
