![FERM BSM1024 [5/108] Assembly](/views2/1858300/page5/bg5.png)
5
EN
• Do not use the machine if the mains cable or
the mains plug is damaged.
• Only use extension cables that are suitable for
the power rating of the machine with a minimum
thickness of 1.5 mm
2
. If you use a extension
cable reel, always fully unroll the cable.
Mains plug replacement (UK only)
If the moulded 3-pin plug attached to the unit is
damaged and needs replacing, it is important
that it is correctly destroyed and replaced by an
approved BS 1363/5A fused plug and that the
following wiring instructions are followed.
The wires in the mains cable are coloured in
accordance with the following code:
blue neutral
brown live
As the colours of the wires in the mains cable
of the unit may not correspond to the coloured
markings identifying the terminals in the plug,
proceed as follows:
- The wire which is coloured blue must be
connected to the terminal which is marked
with the letter N or coloured black.
- The wire which is coloured brown must be
connected to the terminal which is marked
with the letter L or coloured red.
TECHNICAL DATA
BSM1024
Mains voltage 230 V~
Mains frequency 50 Hz
Power input 900 W
No-load speed 380 /min
Sanding belt size 75x533 mm
Sanding pad size 76x135 mm
Protection class IP 20
Weight 3.65 kg
NOISE AND VIBRATION
Sound pressure (Lpa) 86 dB(A) K=3dB
Acoustic power (Lwa) 97 dB(A) K=3dB
Vibration (main grip) 3.92 m/s
2
K=1.5 m/s
2
Wear hearing protection.
Vibration level
The vibration emission level stated in this instruction
manual has been measured in accordance with
a standardised test given in EN 60745; it may be
used to compare one tool with another and as a
preliminary assessment of exposure to vibration
when using the tool for the applications mentioned
- using the tool for different applications, or with
different or poorly maintainted accessories,
may significantly increase the exposure level
- the times when the tool is switched off or when
it is running but not actually doing the job, may
signifi cantly reduce the exposure level
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns
DESCRIPTION (FIG.A)
Your belt sander has been designed for rough
sanding applications on wood, metal, plastics and
painted surfaces.
1. On/off switch
2. Lock-on button
3. Sanding pad
4. Sanding belt roller
5. Clamping lever for sanding belt
6. Centring knob for sanding belt
7. Main grip
8. Auxiliary grip
9. Dustbag connection
10. Carbon brush holder
11. V-belt cover
ASSEMBLY
Before assembly, always switch off the
machine and remove the mains plug from
the mains.
Mounting and removing the sanding belt (fig.A
& B)
Mounting
• Place the machine on its side with the V-belt
cover (11) facing downwards.
• Release the clamping lever (5).
• Mount a sanding belt (12) with the required
grain size around the sanding pad (3) and the
sanding belt rollers (4). Make sure that the
