Xclea H30 Plus QYSDJ01 (2C601RUW) [20/182] Technical data

Technical data

Product name Robot vacuum and mop cleaner Product model QYSDJ01

Rated operating voltage 14.4 V

Rated power 50 W

Lithium battery capacity 5200mAh Rated charging voltage 24 V

Net weight ca. 3.5 kg Dimensions 355 x 355 x 100 mm

Charging time ca. 250 minutes Noise level (low/medium/high) ＜75dB（A）

Dust box capacity 300 ml Cleaning time ca. 250 minutes

Water tank capacity About 250 ml Battery type lithium battery

Product name Dust collector Product model QYJCZ01

Rated power 850 W Rated input 200-240 V~, 50-60 Hz

Rated output 24 V

, 1.2 A Dimensions 358 x 300 x 174 mm

Net weight ca. 4.2 kg Noise level

82 dB(A)

Vacuum time ca. 12 seconds Dust bag capacity ca. 3L

Product name Charging dock Product model QYHCZ01

Rated operating voltage 24 V

Rated power 30 W

Rated input 24 V

, 1.2 A Rated output 24 V

, 1.2 A

Net weight ca. 0.4 kg Dimensions 145 x 140 x 99 mm

Product name Power adapter Power adapter

Rated input 100-240V~, 50-60 Hz, 0.9 A 100-240V~, 50-60 Hz, max. 1.0 A

Rated output 24 V

1.2 A, 28.8 W 24 V

1.2 A, 28.8 W

Product model

System requirements: Android 5.0 or later, iOS 10.0 or later (iPhone 5 or later)

This product includes a WiFi module that supports the 802.11b/g/n transmission protocol.

CMIIT ID:2020DP11783

China: KA3601A-2401200CN ; United Kingdom: KA3601A-2401200BS ;

Korea: KA3601A-2401200KR ; United States: KA3601A-2401200US ;

Japan: KA3601A-2401200JP ; Australia: KA3601A-2401200AU ;

European Union: KA3601A-2401200EU ;

China: DBS036A-2401200C ; United Kingdom: DBS036A-2401200B ;

Korea: DBS036A-2401200K ; United States: DBS036A-2401200U ;

Japan: DBS036A-2401200J ; European Union: DBS036A-2401200G ;
