AENO SM1 (ASM0001) [7/84] _hlk64468933

EN The AENO SM1 Steam Mop is a domestic appliance designed for wet

cleaning of rooms, i.e. degreasing and dust removal from floors, tables, window

sills, carpets and other similar surfaces.

Specifications

Input voltage: 230VAC, 50/60Hz. Rated power: 1000W. Water tank capacity:

380ml. Operating time (Full water tank): up to 35 min. Water consumption: up

to 24 ml/min. Steam pressure: up to 3 bar. Steam temperature: about +110 °C.

Heating time: about 17 sec. Drying protection: Available. Operating conditions:

–5 °С to +40 °С. Dimensions (L×W×H): 251mm × 146mm × 1130mm.

Package Contents

Mop assembly (See assembly drawing a):

❶ – Water tank, ❷ – Water tank plug, ❸ – Water filter cartridge, ❹ – Power

cord, ❺ – Water tank latch lock, ❻ – Steam mop body.

Set of brushes and covers:

❼ – Plastic scraper brush, ❽ – Metal scraper brush, ❾ – Round scraper brush

with cloth cover, ❿ – “Two-in-one” brush with retainer, foam pad and cloth

cover, ⓫ – Main brush, ⓬ – Cloth cover for carpets (large), ⓭ – Cloth cover for

carpets (small), ⓮ – Carpet glider.

Set of tubes and hoses:

⓯ – Extension tube (two pieces), ⓰ – Extension hose.

Accessories:

⓱ – Wall bracket with fasteners (3M tape and screw), ⓴ – Shoulder strap.

⓲ – Quick start guide, ⓳ – Warranty card, V – Descaling pin (use for descaling).

Limitations and Warnings

Do not use aggressive detergents to clean the steam mop and its components

and accessories. All brushes may be cleaned under warm running water, while

cloth covers and cleaners may also be laundered. Be careful when cleaning the

wire brush, as your hands may be injured.
