Dell Latitude 7520-2725 [12/23] External ports

Table 6. Memory specifications (continued)

Description Values

Memory configurations supported

● 8 GB

● 16 GB

● 32 GB

NOTE: Memory is not ungradable.

Internal slots

The following table lists the internal slots of your Latitude 7520.

Table 7. Internal slots

Description Values

M.2

One M.2 2230/2280 Keyed M slot for SSD

NOTE: To learn more about the features of different

types of M.2 cards, see the knowledge base article

SLN301626 at www.dell.com/support.

External ports

The following table lists the external ports on your Latitude 7520.

Table 8. External ports

Description Values

USB ports

● Two One USB 3.2 Gen 1 port one with PowerShare

● Two Thunderbolt 4 ports with DisplayPort Alt Mode/

USB4/Power Delivery

Audio port

One headset (headphone and microphone combo) port

Video port/ports

● One HDMI 2.0 port

● Two Thunderbolt 4 ports with DisplayPort Alt Mode/USB4

Media-card reader

One microSD-card slot

Power-adapter port

Thunderbolt 4 ports USB4 with Power Delivery

Security-cable slot

One wedge-shaped lock slot

Wireless module

The following table lists the Wireless Local Area Network (WLAN) module supported on your Latitude 7520.

Table 9. Wireless module specifications

Description Values

Model number

Intel Wi-Fi 6 AX201, 2x2, 802.11ax with Bluetooth 5.1

(onboard)

12 Specifications of Latitude 7520
