Dell Latitude 7520-2725 [13/23] Wwan module specifications
![Dell Latitude 7520-2725 [13/23] Wwan module specifications](/views2/1864272/page13/bgd.png)
Table 9. Wireless module specifications (continued)
Description Values
Transfer rate
● 2.4 GHz 40M: Up to 574 Mbps
● 5 GHz 80M: Up to 1.2 Gbps
● 5 GHz 160M: Up to 2.4 Gbps
Frequency bands supported
2.4 GHz/5 GHz
Wireless standards
IEEE 802.11a/b/g/n/ac/ax, 160 MHz channel use
Encryption
● 64/128-bit WEP
● 128-bit AES-CCMP
● 256-bit AES-GCMP
● TKIP
Bluetooth
Bluetooth 5.1
WWAN module
The following table lists the Wireless Wide Area Network (WWAN) module supported on your Latitude 7520.
WWAN module specifications
Description
Option one Option two
Model number
● Qualcomm Snapdragon X20 Gigabit
LTE CAT 16 (DW5821e; e-SIM
enabled), WW excluding China,
Turkey, US
● Qualcomm Snapdragon X20 Gigabit
LTE CAT 16 (DW5821e) WW
● Qualcomm Snapdragon X20 Gigabit
LTE CAT 16 (DW5821e) for AT&T,
Verizon, and Sprint, US only
● Qualcomm Snapdragon X20 LTE-A
CAT 9 (DW5829e; e-SIM enabled)
WW excluding China, Turkey, US
● Qualcomm Snapdragon X20 LTE-A
CAT 9 (DW5829e) WW
● Qualcomm Snapdragon X20 LTE-
A CAT 9 (DW5829e) for AT&T,
Verizon, and Sprint, US only
Transfer rate
up to 1 Gbps DL/150 Mbps UL (Cat 16) up to 450 Mbps DL/75 Mbps UL (Cat 9)
Frequency bands supported
● 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19,
20, 25, 26, 28, 29, 30, 32, 38, 39, 40,
41, 42, 43, 46, 66
● HSPA+ (1, 2, 4, 5, 6, 8, 9, 19)
● 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19,
20, 25, 26, 28, 29, 30, 32, 38, 39, 40,
41, 66
● HSPA+ (1, 2, 4, 5, 6, 8)
Network standards
● LTE FDD/TDD
● WCDMA/HSPA+
● GPS/GLONASS/Beidou/Galileo
● LTE FDD/TDD
● WCDMA/HSPA+
● GPS/GLONASS/Beidou/Galileo
Antenna connector
● WWAN Main Antenna X 1
● WWAN Diversity Antenna X 1
● 4 x 4 MIMO Antenna x 2
● WWAN Main Antenna X 1
● WWAN Diversity Antenna X 1
Temperature
● Normal operating temperature:
-30°C to + 70°C
● Extended Operating temperature:
-40°C to +85°C
● Normal operating temperature:
-30°C to + 70°C
● Extended Operating temperature:
-40°C to +85°C
Specifications of Latitude 7520 13
