Display
The following table lists the display specifications of your Latitude 7520.
Table 18. Display specifications
Description Option one Option two Option three Option four
Display type
15.6-inch Full HD (FHD) 15.6-inch FHD Super
Low Power (SLP)
ComfortView Plus Low
Blue Light
15.6-inch FHD with
integrated touch
15.6 inch Ultra High
Definition (UHD)
ComfortView Plus
Low Blue Light
Display-panel technology
TFT , Wide View Angle
(WVA)
TFT, IPS, Super
Low Power (SLP)
ComfortView Plus Low
Blue Light, WVA
TFT, WVA TFT, IPS, Super
Low Power (SLP)
ComfortView Plus
Low Blue Light, WVA
Display-panel dimensions
(active area):
Height
344.16 mm (13.55 in.) 344.16 mm (13.55 in.) 344.16 mm (13.55 in.) 344.16 mm (13.55 in.)
Width
193.59 mm (7.62 in.) 193.59 mm (7.62 in.) 193.59 mm (7.62 in.) 193.59 mm (7.62 in.)
Diagonal
396.24 mm (15.6 in.) 396.24 mm (15.6 in.) 396.24 mm (15.6 in.) 396.24 mm (15.6 in.)
Display-panel native
resolution
1920 x 1080 1920 x 1080 1920 x 1080 3840 x 2160
Luminance (typical)
250 nits 400 nits 250 nits 400 nits
Megapixels
2.07 2.07 2.07 8.29
Color gamut
NTSC 45% sRGB 100% NTSC 45% sRGB 100%
Pixels Per Inch (PPI)
141 141 141 283
Contrast ratio (typ)
700:1 700:1 700:1 1000:1
Response time (min)
25 milli-second (ms) 25 ms 25 ms 19 ms
Refresh rate
60 Hz 60 Hz 60 Hz 60 Hz
Horizontal view angle
80/80 degrees (min) 80/80 degrees (min) 80/80 degrees (min) 80/80 degrees (min)
Vertical view angle
80/80 degrees (min) 80/80 degrees (min) 80/80 degrees (min) 80/80 degrees (min)
Pixel pitch
0.17925 mm 0.17925 mm 0.17925 mm 0.08964 mm
Power consumption
(maximum)
4.6 W 4.5 W 4.6 W 4.5 W
Anti-glare vs glossy
finish
Anti-glare Anti-glare Anti-glare Anti-glare
Touch options
Non-touch Non-touch Touch Non-touch
Specifications of Latitude 7520 19
