Table 15. Touchpad specifications (continued)
Description Option 1 Option 2
Microsoft knowledge base article 4027871 at
support.microsoft.com.
knowledge base article 4027871
at support.microsoft.com.
Power adapter
The following table lists the power adapter specifications of your Latitude 7520.
Table 16. Power adapter specifications
Description Option one Option two
Type
65 W AC adapter, USB-C 90 W, AC adapter, USB-C
Input voltage
100 VAC-240 VAC 100 VAC-240 VAC
Input frequency
50 Hz-60 Hz 50 Hz-60 Hz
Input current (maximum)
1.70 A 1.50 A
Output current (continuous)
● 20 V/3.25 A (Continuous)
● 15 V/3 A (Continuous)
● 9.0 V/3 A (Continuous)
● 5.0 V/3 A (Continuous)
● 20 V/4.5 A (Continuous)
● 15 V/3 A (Continuous)
● 9.0 V/3 A (Continuous)
● 5.0 V/3 A (Continuous)
Rated output voltage
20 VDC/15 VDC/9 VDC/5 VDC 20 VDC/15 VDC/9 VDC/5 VDC
Temperature range:
Operating
0°C to 40°C (32°F to 104°F) 0°C to 40°C (32°F to 104°F)
Storage
-40°C to 70°C (-40°F to 158°F) -40°C to 70°C (-40°F to 158°F)
Dimensions
Width (mm/inch) 112 mm (4.41 in.) 130 mm (5.1 in.)
Depth (mm/inch) 51 mm (2.01 in.) 66 mm (2.6 in.)
Height (mm/inch) 28 mm (1.1 in.) 22 mm (0.8 in.)
Weight (kg/lb) 201 g (0.44 lb) 291 g (0.64 lb)
Battery
The following table lists the battery specifications of your Latitude 7520.
Table 17. Battery specifications
Specifications Option 1 Option 2
Type 4-cell, 63 WHr, optional
with ExpressCharge or
Long Life Cycle
3-cell, 42 WHr, optional
with ExpressCharge or
Long Life Cycle
Voltage (VDC) 15.2 VDC 11.40 VDC
Weight (maximum) 0.26 kg (0.58 lb) 0.21 kg (0.46 lb)
Dimensions:
Specifications of Latitude 7520 17
