Caution!
The disc rotates at high speed in the drive unit.
Use of worn, damaged, or non-standard
CD-ROM discs can adversely affect the drive
and cause the disc to shatter or crush while in
use. Disc crush can only occur when you use a
damaged CD-ROM disc in the drive. It is an
extremely rare occurrence, but there are steps
which can be taken to prevent it.
Always check your discs before inserting
them into the drive.
1. Take care not to use worn, cracked,
damaged, warped or poor quality
CD-ROMs, as this may cause damage to
your drive.
2. Check the clear plastic on the center of
the disc, cracks here are the main
cause of disc crush.
3. Do not play CD-ROMs which are a non-
standard (I.e. non-circular)shape, such as
heart shaped discs, or discs in the shape
of a business card.
How can you keep your discs from becoming
damaged?
1. When not in use, remove discs from the
drive.
2. Keep discs in the packaging supplied with
them and out of direct sunlight and away
from heat sources.
Excessive vibration or a sudden jolt to the drive
during operation may cause a malfunction.
Avoid exposing the drive to sudden changes in
temperature as it may cause condensation to
collect inside the drive.
Copyright
©
2006
LG Electronics U.S.A. Inc.
1000 Sylvan Ave.
Englewood Cliffs NJ 07632
U. S. A.
or http://www.lgusa.com
LG Electronics Canada Inc.
550 MATHESON Blvd. East Mississauga.
Ontario L4Z4G3 Canada
LG Electronics Deutschland GMBH
Jakob-Kaiser-Straße 12,
D-47877 Willich, Germany
LG Electronics U. K. Ltd.
LG House, 250 Bath Road,
Slough Berkshire SL1 4DX
United Kingdom
Goldstar France E.U.R.L
Paris Nord II 22, Avenue des
Nations-B.P.50372 VILLEPINTE
95945 ROISSY CDG CEDEX France
LG Electronics Italia S.P.A.
Centro Direzione “IL Quadrate” Via
Modigliani, 20090 Segrate (MI) Italy
LG Electronics España
Complejo Europa Empressaries (Edif.Bruselas)
Ctra. N-VI 28230 Las Rozas Madrid Spain
LG Electronics Australia Pty Ltd.
2 Wonderland drive, Eastern creek, NSW
2766
or http://www.lge.com.au
LG Electronics Portugal S.A.
Quinta da Fonte – Edifício D. Amélia
Rua Vítor Câmara, nº2, Piso 2
2700-229 Paço d´ Arcos, Portugal
ou www.lge.pt
©
2006 Made by
P/NO. 3828HM1058N
Ver. A
Please visit www.lgservice.com and install the program,
“LG ODD Online F/W update.” By using the program,
you can automatically check the latest information about
FirmWares and update the FirmWare.
