Features
Important Precautions
• Enhanced-IDE (ATAPI) interface.
• Power tray loading and ejection of disc. (The disc can also be ejected manually.)
• Combination CD-R/RW, DVD-R/RW, DVD-R DL, DVD+R/RW, DVD+R DL,
DVD-RAM Drive functions into one drive.
• Supports Region playback control Phase II.
• Supports Windows 2000 Professional, XP Home Edition, XP Professional, Vista.
• Automatic buffer underrun error prevention technology.
Follow these precautions when handling the drive or discs.
•
Please take notice that the manufacturer of this equipment does not offer any warranty
against data loss due to inappropriate installation or handling, or direct or indirect damages.
• Please take notice that the manufacturer will bear no responsibility for direct or indirect
damages caused by the use of this product or its malfunction.
• Please take notice that the manufacturer will bear no responsibility for damage to data
caused by this product.
• Please backup (copy) all important data as a protection against data loss.
• Avoid placing the drive in a location subject to:
- high humidity, high temperature, excessive dust, mechanical vibration, direct sunlight
We recommend using the drive in a horizontal or vertical position. Do not use it in tilted position.
• Don’t move the drive suddenly from a cold place to a warm one or raise the room
temperature suddenly. Condensation may occur, causing abnormal operation.
• Make sure to remove the disc before moving the drive. The disc may become damaged,
causing data loss.
• Be careful to prevent foreign objects, such as liquids or metal, from entering the drive.
In case a foreign object enters the drive, please consult the dealer where the drive was
purchased.
• Don’t interrupt the electric power while the drive is operating.
• When connecting two IDE devices to the Primary or Secondary connectors, make sure
that the two devices are not configured as both Master, or both Slave. If they are both set
the same, Windows may fail to run or recognize the drives.
• The total length of the IDE cable should be no more than 18 inches (about 45 cm).
2
WARNING: Only drives bearing the logo Compact Disc ReWritable Ultra Speed can
write or erase Ultra Speed CD-RW media.
Ultra Speed CD-RW Media may be recognized by the same Compact Disc ReWritable
Ultra Speed logo on the disc label or packaging material.
Attempting to write to Ultra Speed CD-RW media using CD-RW drives NOT bearing the
logo Compact Disc ReWritable Ultra Speed may result in data loss.
