Omnimount PLAY20 [9/24] X200mm
![Omnimount PLAY20 [9/24] X200mm](/views2/1867815/page9/bg9.png)
PN:888-45-233-W-01 revC
75x75mm
100x100mm
100x200mm
200x200mm
200x100mm
100mm (3-15/16”)
75mm (2-15/16”)
100mm (3-15/16”)
75mm (2-15/16”)
100mm (3-15/16”)
200mm (7-7/8”)
200mm (7-7/8”)
200mm (7-7/8”)
100mm (3-15/16”)
200mm (7-7/8”)
VESA PATTERN CONFIGURATIONS
A
B
C
D
