Bosch GLM 50-27 CG Li-Ion [28/477] Inserting changing the battery

28 | English

Digital laser measure GLM 50-27 CG GLM 50-27 C

Data transmission

Bluetooth® Bluetooth® 4.2

(Low Energy)

Bluetooth® 4.2

(Low Energy)

Operating frequency range 2402–2480MHz 2402–2480MHz

Max. transmission power 8mW 8mW

A) When measuring from the front edge of the measuring tool, this applies for high reflectivity of the

target (e.g. a wall painted white), weak background lighting and a 25°C operating temperature; a

distance-dependent deviation of ±0.05mm/m must additionally be factored in.

B) When measuring from the front edge of the measuring tool, this applies for high reflectivity of the

target (e.g. a wall painted white), strong background lighting, 25°C operating temperature and

large altitudes. In addition, a deviation of ±0.15mm/m must be taken into account, depending on

the distance.

C) In continuous measurement mode, the max. operating temperature is +40 °C.

D) Only non-conductive deposits occur, whereby occasional temporary conductivity caused by con-

densation is expected.

E) Bluetooth® deactivated

F) For additional technical data, visit: https://www.bosch-professional.com/ecodesign

G) When using Bluetooth® Low Energy devices, it may not be possible to establish a connection de-

pending on the model and operating system. Bluetooth® tools must support the GATT profile.

The serial number (11) on the type plate is used to clearly identify your measuring tool.

Inserting/Changing the Battery

Always replace all the batteries/rechargeable batteries at the same time. Only use

batteries/rechargeable batteries from the same manufacturer and which have the

same capacity.

When inserting the batteries, ensure that the polarity is correct according to the il-

lustration on the inside of the battery compartment.

u Take the batteries out of the measuring tool when you are not using it for a pro-

longed period of time. The batteries can corrode and self-discharge during prolonged

storage.

Never store the measuring tool without an inserted battery compartment

cover(13) or lithium-ion battery pack(19) (accessory), particularly in dusty or hu-

mid environments.

1 609 92A 6XT | (03.09.2021) Bosch Power Tools
