18 | English
1 609 92A 2PP | (19.8.16) Bosch Power Tools
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
While reading the operating instructions, unfold the graphics
page for the machine and leave it open.
Intended Use
In conjunction with a dust-category M vacuum cleaner and
with firm support of the cutting guide, the machine is intend-
ed to cut or slot mainly mineral materials such as reinforced
concrete, brickwork and road surfaces without the use of wa-
ter.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Handle (insulated gripping surface)
2 Release lock
3 Release button for the cutting unit
4 Cutting-depth scale
5 Button for depth stop adjustment
6 Depth stop
7 Chaser rollers
8 Working-direction arrow
9 Spindle lock button
10 On/Off switch
11 Service indicator(GNF 35 CA)
12 Vacuum hose*
13 Vacuum connection
14 Parallel guide(GNF 20 CA)*
15 Guide bolt for parallel guide(GNF 20 CA)*
16 Grinder spindle
17 Mounting flange
18 Diamond cutting disc*
19 Spacer discs
20 Clamping nut
21 Two-pin spanner for clamping nut*
22 Break-out tool*
23 Direction of rotation
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Wall Chaser GNF 20 CA GNF 35 CA
Article number
0 601 612 5.. 0 601 621 7..
Rated power input
W 900 1400
Output power
W 520 750
No-load speed
min
-1
9300 9300
Max. diameter for diamond cutting discs
mm 115 150
Working with one diamond cutting disc
– Cutting discs width, min.
– Cutting discs width, max.
mm
mm
1.6
2.2
2.0
2.5
Working with two diamond cutting discs
– Cutting discs width, min.
– Cutting discs width, max.
mm
mm
2 x 1,6
2 x 2,2
2 x 2,0
2 x 2,5
Mounting bore
mm 22.2 22.2
Slot depth
mm 0 – 20 0–35
Slot width
mm 7 – 23 7–39
Weight according to EPTA-Procedure 01:2014
kg 3.4 4.7
Protection class
/II /II
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
OBJ_BUCH-126-003.book Page 18 Friday, August 19, 2016 1:30 PM
