5
ENGLISH
(Original instructions)
Features (Fig. A)
1. Variable speed switch
2. Lock-on button
3. Forward/reverse slider
4. Drilling mode selector
5. Chuck
6. Depth stop
7. Side handle
Additional safety instructions for
hammer drill
• Wear ear protectors with impact drills.
Exposure to noise can cause hearing
loss.
• Use auxiliary handles supplied with the
tool. Loss of control can cause personal
injury.
• Hold power tool by insulated gripping
surfaces when performing an operation
where the cutting tool may contact
hidden wiring or its own cord. Contact
with a “live” wire will also make exposed
metal parts of the power tool “live” and
shock the operator.
• Use clamps or another practical way to
secure and support the workpiece to a
stable platform. Holding the work by
hand or against your body leaves it
unstable and may lead to loss of control.
• Before drilling into walls, floors or
ceilings check for the location of wiring
and pipes.
• Avoid touching the tip of a drill bit just
after drilling, as it may be hot
Assambly
Warning! Before assembly, make sure that
the tool is switched o and unplugged.
Fitting the side handle and depth
stop (Fig. B)
Turn the grip counterclockwise until you can
slide the side handle (7) onto the front of
the tool as shown.
• Rotate the side handle into the desired
position.
• Insert the depth stop (6) into the
mounting hole as shown.
• Set the drilling depth as described below.
• Tighten the side handle by turning the
grip clockwise.
Fitting a drill bit or screwdriver bit
Keyed chuck (Fig. C)
• Open the chuck by turning the sleeve (9)
counterclockwise.
• Insert the bit shaft (8) into the chuck.
• Insert the chuck key (10) into each hole
(11) in the side of the chuck and turn
clockwise until tight.
Removing and refitting the chuck
(Fig. D)
• Open the chuck as far as possible.
• Remove the chuck retaining screw,
located in the chuck, by turning it
clockwise using a screwdriver.
• Tighten an Allen key into the chuck and
strike it with a hammer as shown.
• Remove the Allen key.
• Remove the chuck by turning it
counterclockwise.
• To refit the chuck, screw it onto the
spindle and secure it with the chuck
retaining screw.
Use
Warning! Let the tool work at its own pace.
Do not overload.
Warning! Before drilling into walls, floors or
ceilings, check for the location of wiring and
pipes.
Selecting the direction of rotation
(Fig. E)
For drilling and for tightening screws, use
forward (clockwise) rotation. For loosening
screws or removing a jammed drill bit, use
reverse (counterclockwise) rotation.
• To select forward rotation, push the
forward/reverse slider (3) to the centre
position.
