10
ENGLISH
burn the lower guard, the kerf insert and other plastic
parts.
Use clamps to support the workpiece whenever
possible. If supporting the workpiece by hand, you
must always keep your hand at least 100 mm from
either side of the saw blade. Do not use this saw to
cut pieces that are too small to be securely clamped
or held by hand. If your hand is placed too close to the
saw blade, there is an increased risk of injury from blade
contact.
The workpiece must be stationary and clamped or
held against both the fence and the table. Do not feed
the workpiece into the blade or cut “freehand” in any
way. Unrestrained or moving workpieces could be thrown
at high speeds, causing injury.
Push the saw through the workpiece. Do not pull the
saw through the workpiece. To make a cut, raise the
saw head and pull it out over the workpiece without
cutting, start the motor, press the saw head down and
push the saw through the workpiece. Cutting on the
pull stroke is likely to cause the saw blade to climb on top
of the workpiece and violently throw the blade assembly
towards the operator.
Never cross your hand over the intended line of
cutting either in front or behind the saw blade.
Supporting the workpiece “cross handed” i.e. holding the
workpiece to the right of the saw blade with your left hand
or vice versa is very dangerous.
Do not reach behind the fence with either hand closer
than 100 mm from either side of the saw blade, to
remove wood scraps, or for any other reason while
the blade is spinning. The proximity of the spinning saw
blade to your hand may not be obvious and you may be
seriously injured.
Inspect your workpiece before cutting. If the
workpiece is bowed or warped, clamp it with the
outside bowed face toward the fence. Always make
certain that there is no gap between the workpiece,
fence and table along the line of the cut. Bent or
warped workpieces can twist or shift and may cause
binding on the spinning saw blade while cutting. There
should be no nails or foreign objects in the workpiece.
Do not use the saw until the table is clear of all
tools, wood scraps, etc., except for the workpiece.
Small debris or loose pieces of wood or other objects
that contact the revolving blade can be thrown with high
speed.
Cut only one workpiece at a time. Stacked multiple
workpieces cannot be adequately clamped or braced and
may bind on the blade or shift during cutting.
Ensure the mitre saw is mounted or placed on a level,
fi rm work surface before use. A level and fi rm work
surface reduces the risk of the mitre saw becoming
unstable.
Plan your work. Every time you change the bevel or
mitre angle setting, make sure the adjustable fence is
set correctly to support the workpiece and will not
interfere with the blade or the guarding system.
Without turning the tool “ON” and with no workpiece on the
table, move the saw blade through a complete simulated
cut to assure there will be no interference or danger of
cutting the fence.
Provide adequate support such as table extensions,
saw horses, etc. for a workpiece that is wider or
longer than the table top. Workpieces longer or wider
than the mitre saw table can tip if not securely supported.
If the cut-off piece or workpiece tips, it can lift the lower
guard or be thrown by the spinning blade.
Do not use another person as a substitute for a table
extension or as additional support. Unstable support
for the workpiece can cause the blade to bind or the
workpiece to shift during the cutting operation pulling you
and the helper into the spinning blade.
The cut-off piece must not be jammed or pressed by
any means against the spinning saw blade.
If confi ned, i.e. using length stops, the cut-off piece could
get wedged against the blade and thrown violently.
Always use a clamp or a fi xture designed to properly
support round material such as rods or tubing. Rods
have a tendency to roll while being cut, causing the blade
to “bite” and pull the work with your hand into the blade.
Let the blade reach full speed before contacting the
workpiece. This will reduce the risk of the workpiece
being thrown.
If the workpiece or blade becomes jammed, turn the
mitre saw off. Wait for all moving parts to stop and
disconnect the plug from the power source and/
or remove the battery pack. Then work to free the
jammed material. Continued sawing with a jammed
workpiece could cause loss of control or damage to the
mitre saw.
After fi nishing the cut, release the switch, hold the
saw head down and wait for the blade to stop before
removing the cut-off piece. Reaching with your hand
near the coasting blade is dangerous.
Additional safety instructions for mitre saws
Hold the handle fi rmly when making an incomplete cut
or when releasing the switch before the saw head is
completely in the down position. The braking action of
the saw may cause the saw head to be suddenly pulled
downward, causing a risk of injury.
The intended use is described in this instruction manual.
The use of any accessory or attachment or performance
