![Kress KU334 [8/16] Accessories](/views2/1889196/page8/bg8.png)
8
EN
ACCESSORIES
Auxiliary handle 1
Depth gauge 1
We recommend that you purchase your accessories
from the same store that sold you the tool. Choose the
type according to the work you intend to undertake.
Refer to the accessory packaging for further details.
Store personnel can assist you and offer advice.
OPERATING
INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
The machine is intended for hammer drilling in
concrete, brick and stone as well as for light chiseling
work.
WARNING! Before any work on the
machine itself, pull the mains plug.
OPERATION
Action Figure
Selecting The Operating Mode See Fig. A
Inserting Drill Bits See Fig. B1
Removing Drill Bits See Fig. B2
Adjusting the Auxiliary Handle See Fig. C
Using the Depth Gauge See Fig. D
On/Off Switch See Fig. E
Lubrication Machine
Caution: Keep the container
of grease away from children.
See Fig. F
Replacing the Brushes
● Unscrew the carbon brush cap
with screwdriver.
● When brushes need replacement
always renew both brushes.
● Completely screw down the
carbon brush cap. Check that the
tool is working. Before use, allow
it run for a few minutes to enable
the brushes to settle.
See Fig. G1,
G2
CONSTANT ELECTRONIC
CONTROL
/
OVERLOAD PROTECTION /
WORKING HINTS FOR
YOUR TOOL
1. Reduce the pressure on the drill bit when it is about
to break through. This will prevent the drill from
jamming.
2. When drilling a large hole, rst drill a pilot hole using
a smaller drill bit.
3. Always apply pressure to your drill bit in a straight
line, and if possible at right angles to the workpiece.
4. Never change the operating mode whilst the drill is
running.
5. Do not apply excessive pressure to the tool when
chiseling. Expressive force does not speed up the
work.
