VTS reserves the right to implement changes without prior notice.
www.vtsgroup.com Page 11 of 16 ver. 2.0 (11.2021)
Command table:
Command no.
Function
Parameters
1
Set device address
1-247 (1 – default value)
2
Set the baud rate
24 – 2400 bit/s
48 – 4800 bit/s
96 – 9600 bit/s
192 – 19200 bit/s = default value
384 – 38400 bit/s
576 – 57600 bit/s
1152 – 115200 bit/s
3
Set parity bits
0 – NO PARITY, no parity bit (default value)
1 – EVEN PARITY
2 – ODD PARITY
4
Set stop bits
1 – 1x STOP, 1 stop bit (default value)
2 – 2x STOP, 2 stop bits
5
Function on / off
0 – ABClogic off (off by default)
1 – ABClogic on
6
Device reset
1 – software reset of the device
2 – software reset of sensor module
Notes:
Reading registers from addresses not listed in this table results in 0x02 exception.
Specifying an incorrect or out-of-range parameter value results in entering the value
0xEEEE into the command register.
The device is configured by writing three registers (password / command /
parameter) at the same time using the 0x10 function with the corresponding values
– according to the command table, or by writing single registers (using 0x06 or 0x10
function) with the latter writing of a (valid) password causing the execution of the
command.
During a single password entry (both with function 0x06 and 0x10) in case of a
password match, the correctness of information in command and parameter
registers is checked and if correct, the command is executed.
