VTS VENTUS PRO PVS PO 50 EC [13/16] Reading the contents of a group of output registers 0x03
![VTS VENTUS PRO PVS PO 50 EC [13/16] Reading the contents of a group of output registers 0x03](/views2/1893541/page13/bgd.png)
VTS reserves the right to implement changes without prior notice.
www.vtsgroup.com Page 13 of 16 ver. 2.0 (11.2021)
4.2.1. Reading the contents of a group of output registers (0x03)
Command format:
Description
Size [Bytes]
Values
Notes
Address
1
1 – 247
Function code
1
0x03
Data block address
2
0x0000 – 0xFFFF
Number of registers (N)
2
1 – 125
CRC check sum
2
0x0000 – 0xFFFF
See section 4.4
Response format:
Description
Size [Bytes]
Values
Notes
Address
1
1 – 247
Function code
1
0x03
Byte counter
1
2* n
Register values
2 * N
Acc. to register map
CRC check sum
2
0x0000 – 0xFFFF
See section 4.4
Error format:
Description
Size [Bytes]
Values
Notes
Address
1
1 – 247
Function code
1
0x83
Error code
1
1– 4
See section 4.2.4
CRC check sum
2
0x0000 – 0xFFFF
See section 4.4
4.2.2. Writing single 16-bit registers (0x06)
Command format:
Description
Size [Bytes]
Values
Notes
Address
1
1 – 247
Function code
1
0x06
Register address
2
0x0000 – 0xFFFF
Value to be stored
2
0x0000 – 0xFFFF
CRC check sum
2
0x0000 – 0xFFFF
See section 4.4
