Repair
312066ZAF 41
Primary Heaters
Heater Element
1. Turn main power OFF . Disconnect power
supply.
2. Perform the Pressure Relief Procedure, page 25.
3. Wait for heaters to cool.
4. Remove heater shroud.
5. See FIG. 6, page 42. Disconnect heater element
wires from heater wire connector. Test with
ohmmeter.
6. To remove heater element, first remove
thermocouple (310) to avoid damage, see step
Thermocouple, page 43.
7. Remove heater element (307) from housing (301).
Be careful not to spill any fluid left in housing.
8. Inspect element. It should be relatively smooth and
shiny. If there is a crusted, burnt, ash-like material
adhered to element or sheath shows pitting marks,
replace element.
9. Install new heater element (307), holding mixer
(309) so it does not block thermocouple port (P).
10. Reinstall thermocouple. See page Thermocouple,
page 43.
11. Reconnect heater element leadwires to heater wire
connector.
12. Replace heater shroud.
Line Voltage
The primary heaters output their rated wattage at 230
Vac. Low line voltage will reduce power available and
the heaters will not perform at full capability.
Total Heater
Wattage Element Ohms
6,000 1500 30-35
7,650 2550 18-21
10,200 2550 18-21
