Repair
Replace Replace
Replace
Pressure Pressure
Pressure
Transducers Transducers
Transducers
1.PerformShutdown,page46.
2.PerformPressureReliefProcedure,page45.
3.Disconnecttransducercables(405)from#6and
#7connectorsontheMCM.
4.Removewiretiesconstrainingtransducercable
andremovecablefromcabinet.
5.Installo-ring(416)onnewtransducer(405).
6.Installtransducerinmanifold.Markendofcable
withtape(red=transducerA,blue=transducerB).
7.Routenewcableintocabinetandthreadinto
bundleasbefore.Attachcabletiestobundle
asbefore.
8.ConnectAsidepressuretransducercable
toMCMport#6.ConnectBsidepressure
transducercabletoMCMport#7.
333024T 61
