Parts
22 309577Y
9 239922 SEAT, intake; carbide; includes
items 10 and 11
1 1
244199 SEAT, intake; carbide; includes
items 10 and 11
1 1
240918 SEAT, intake; carbide; includes
items 10 and 11
1
192642 SEAT, intake; carbide; includes
items 10 and 11
1
196866 SEAT, intake; carbide; includes
items 10 and 11
1
193395 SEAT, intake; carbide; includes
items 10 and 11
1
10* 107079 O-RING; PTFE 1 1 1
108526 O-RING; PTFE 1 1 1
107098 O-RING; PTFE 1 1
11* 105445 BALL, intake; sst; 0.5 in. (13
mm)
1
1 1
102972 BALL, intake; sst; 0.875 in. (22
mm)
1 1 1
107167 BALL, intake; sst; 1 in. (25 mm) 1 1
12 192624 GUIDE, ball 1 1 1
193027 GUIDE, ball 1 1 1
193391 GUIDE, ball 1 1
13* 117450 SEAL, u-cup, piston; UHMWPE 1 1 1
117449 SEAL, u-cup, piston; UHMWPE 1 1 1
117448 SEAL, u-cup, piston; UHMWPE 1 1
14* 15B078 BUSHING, piston 1 1
15J197 BEARING, lower 1 1 1
15B079 BUSHING, piston 1 1
17F958 BEARING, lower 1
15* 156593 O-RING; BUNA-N 1 1 1
156633 O-RING; BUNA-N 1 1 1
160325 O-RING; BUNA-N 1 1
16* 105444 BALL, piston; sst; 0.3125 in. (8
mm)
1 1 1
101947 BALL, piston; sst; 0.375 in. (10
mm)
1 1 1
107203 BALL, piston; sst; 0.5625 in. (14
mm)
1 1
17* 15B075 BUSHING, rod 1
1 1
15B074 BUSHING, rod 1 1 1
15B076 BUSHING, rod 1 1
18* 15J196 BUSHING, pump 1 1 1 1
17F957 BUSHING, pump 1
Ref. Part Description
Qty.
246830 246831 262647 246832 24Y175 25P857 25P858 25P944
