Comprag ACP-2 [7/56] Device and mechanism

CONTRACOR

Compressed air aftercooler ACE/ACP

ENGLISH

2. Device and mechanism

2.1 Function

ACP/ACE aftercoolers of compressed air remove condensate and oil from the air stream

during abrasive blast cleaning. Recommend for use between air compressor and

sandblasting equipment.

2.2 Technical information

Product code 14390011 14390012 14390013 14390001 14390002 14390003

Model ACE-1 ACE-2 ACE-3 ACP-1 ACP-2 ACP-3

Maximum working

pressure, bar

Capacity (m

/min) 20 30 45 20 30 45

Voltage, V 380~ /50 Hz -

Maximum current, A 0,44 1,59 1,68 -

Power, kW 0,3 0,7 0,9 -

Pressure of air motor min/max,

bar

- 2 / 6

Consumption of compressed

air with min/max pressure

of air motor, m3/min

- 0,6 / 1,4

Thread connection, inlet 1 1/2” 2” 3” 1 1/2” 2” 3”

Thread connection, outlet 1 x 3/4”

1 x 1”

1 x 1 1/4”

1 x 3/4”

1 x 1 1/4”

1 x 1 1/2”

1 x 3/4”

1 x 1 1/4”

2 x 1 1/2”

1 x 3/4”

1 x 1”

1 x 1 1/4”

1 x 3/4”

1 x 1 1/4”

1 x 1 1/2”

1 x 3/4”

1 x 1 1/4”

2 x 1 1/2”
