- 5 -
N Only for B760M DS3H.
P Only for B760M DS3H DDR4.
KB_MS_USB
CPU_FAN
SYS_FAN1
ATX
B760M DS3H
B760M DS3H DDR4
F_ AUDIO
SPDIF_O
AUDIO
BAT
ATX_12V_2X4
CODEC
CLR_CMOS
RST
U32_LAN
PCIEX16
PCIEX1_1
iTE
®
Super I/O
Realtek
®
2.5GbE LAN
LED_C F_USB2 SYS_FAN3
SPI_TPM F_PA NEL
SATA3 5 4
SATA3
7
6
VGA
HDMI
80
80
M_BIOS
LPT
QFLASH_PLUS
RST_SW P
F_U32
U32G2C
U32
M2P_ S B
M2A_CPU
D_LED
SYS_FAN2
F_USB1
QFLED
PCIEX1_2
DUAL_DP
COM
USB 2.0 Hub
LGA1700
Intel
®
B760
DDR5 _A1 N
DDR4_A1 P
DDR5_A2 N
DDR4_A2 P
DDR5_B1 N
DDR4_B1 P
DDR5_B2 N
DDR4_B2 P
(Note) The temperature sensor is on the back of the motherboard.
Temperature sensor
(Note)
